Power System Analysis

Power System Analysis

A powerful set of analysis and optimization software products for design, simulation, and planning of LV and MV electrical systems utilizing an intelligent one-line diagram and the flexibility of a multi-dimensional database.

Key Benefits

  • Load Flow & Voltage Drop

    Load flow analysis and voltage drop calculations with accurate and reliable results

  • Power Panel Schedules

    Easily design and analyze electrical distribution panel boards and load schedules.

  • Short Circuit

    The Short Circuit module determines fault currents and automatically compares them against manufacturer ratings.

  • Motor Acceleration

    Examine the effects of starting motors & load impacts within your system

  • Harmonics

    Simulate harmonic current and voltage sources, reduce nuisance trips, and report distortion limit violations.

  • DC Load Flow

    Integrated AC & DC System Load Flow

  • DC Short Circuit

    Evaluate system fault conditions and assess protective device ratings for direct current systems

  • PV Array & Solar Panel

    Model unlimited solar panels individually or in groups to form a solar array



White Papers
