Built-in conversion tools:

• SKM PowerTools® - Dapper® / Captor™ PTW32
• ESA EasyPower®
• Siemens PSS®E

Other available conversion programs:

• DIgSILENT® PowerFactory
• CYME
• Neplan®
• Power Analytics® / EDSA®
• DCSDM

• One-line diagram conversion based on original layout
• Data range checking
• Typical data substitution for missing parameters
• Data validation
• Data consistency checking
• Automatic protective device settings mapping
• Import of user created Time-Current Curves
• Support for multiple one-line drawings and MCCs into composite networks

Base Data Exchange Tools

Built-in Data Exchange tools are available as part of Base Package:

• Export to DXF - AutoCAD / MicroStation
• Export to Metafile
• Import from PSSE (RAW, SEQ & DYR files)
• Import from IEEE format
• Export Report to MS Excel
• Export Report to MS Word
• Export Report to PDF
• Export Configuration Status
• Export to COMTRADE Format
• Export load ticket for induction machines
