Improve system protection and avoid possible misoperation by incorporating transformer inrush into system protection studies. Utilize a convenient and validated approach for transformer inrush current calculation with phasor-based transient stability analysis.

Inrush Simulation using Magnetization Characteristics
Sympathetic Inrush - Single & Multi-Transformer
Verified & Validated Calculations

Key Features

Detailed Transformer Modeling
Transformer Energization Inrush
Sympathetic Inrush
Fault Clearance Inrush
Simulate the Impact of Inrush Current
Evaluate and Size Pre-magnetizing Transformers
Utilize Transformer Magnetization Curve Points
Consider Transformer Remnant Flux
Graphical Result Plots

Magnetizing inrush current in transformers results from any abrupt changes of the magnetizing voltage. This may be caused by energizing an unloaded transformer, occurrence of an external fault, voltage recovery after clearing an external fault and out-of phase synchronizing of connected generator. Therefore, a detailed analysis of the magnetizing inrush current under various conditions is necessary to evaluate voltage dip, and protective relay operation.
