Découvrez toutes les nouvelles fonctionnalités de Caneco BIM dans cette vidéo.
La suite logicielle tout-en-un pour l'ingénierie électrique.
Learn how ETAP's Simplified Electrical Digital Twin and Electric Copilot™ are helping to solve the key challenges being faced in electrical design and analysis, such as increasing system complexity, aging infrastructure, demand for real-time data, regulatory pressure, and skill gaps. The product demonstration illustrates the innovative and newest features of ETAP, including new modeling functionality, document tagging, composite networks, component classification, advanced preferences, and artificial intelligence with Electric Copilot.
Multiple arc flash incident energy mitigation methods are available, but how does an engineer know which is best for their client? This presentation identifies an approach to follow to pick the method, considering effectiveness, practicality, feasibility, and overall best option for realistic study results. With extensive experience with arc flash studies for many clients of all sizes, Mangan provides a real world demonstration of a project for a refinery client. The interplay between motor starting and arc flash analysis was evaluated, and mitigation recommendations were customized for the system. The challenges encountered during mitigation are identified, and the proposed solution is analyzed using ETAP Load Flow, Short Circuit, Arc Flash and Motor Acceleration Analysis. Safe motor operation, safe motor starting and arc flash protection are provided through customized mitigation methods and thoughtful system design.
The escalating demand for fleet electrification across the U.S. presents a significant challenge to existing distribution infrastructure, necessitating EV charging management strategies to meet electrical energy demands and address power quality issues. Level 2 and Level 3 EV chargers, equipped with power electronic converters and PWM technology, generate non-sinusoidal currents, exacerbating power quality concerns at individual sites. The effect of rapid voltage changes (RVC) introduced by this equipment is also discussed. This case study features insights and observations from field-recorded measurements of unbalanced (per-phase) harmonic distortions at a site with over 300 electric van charging stations. The unbalanced harmonic analysis (UBHA) conducted by Eradeh Power Consulting using ETAP Software for the site, revealed distortion limits being exceeded for individual phase currents and voltages as well as power distribution equipment rating overloads (such as transformer K-rating and cable thermal limits). The presentation also discusses how unbalanced harmonic distortions calculated within the site and at the point of common coupling (PCC) can be mitigated using techniques such as the use of active / passive harmonic filters amongst others.
This case study discusses the challenges faced by BBraun Medical, a manufacturing facility of medical products, due to unplanned outages and the lack of an optimized load shedding system. This demonstration discusses the use of ETAP Real-Time Intelligent Load Shedding (ILS), and ETAP's digital twin modeling capabilities, to distinguish between different subsystems and validate the ILS solution. The ILS solution provided a quick response to islanding conditions, ensuring the continuous operation of critical loads while shedding non-critical loads, thus minimizing production loss during outages. The solution also offered load optimization, flexible load priority modifications, and real-time monitoring capabilities. Overall, the ETAP ILS solution helped BBraun Medical operate safely during disturbances and minimize the impact of utility disturbances, providing an effective load shedding solution.
This Red Sea Project is a groundbreaking endeavor in Saudi Arabia under the Saudi Vision 2030 economic development program. The project is powered by a fully renewable energy system, including large-scale solar photovoltaic (PV) system and a substantial 1.3 GWh energy storage system, effectively providing 100% clean energy to the development. As the Engineering, Procurement and Construction firm for this project, SEPCOIII has been involved with the design and construction of a wide range of permanent utility assets, including support facilities such as desalination plants, power generation facilities and distribution networks for water, electricity and natural gas. In this presentation, learn how SEPCOIII relied on ETAP's Advanced Distribution Management System (ADMS) to assist with the technology challenges for the project’s distributed energy power system, and how the solution is being used to manage and supervise the power distribution system to achieve better optimizations and improve system stability.
The Abu Dhabi National Oil Company, also known as ADNOC, is the state-owned oil company of the United Arab Emirates, and is the world's 12th largest oil company by production. ADNOC is committed to sustainability and has implemented various initiatives to reduce its carbon footprint, enhance operational efficiency, and support the UAE's goal for renewable energy and climate change mitigation. For ADNOC’s many facilities, whether independent power plants or other electrical networks, the challenge is how to provide training to operators, to not only get familiar with the operation management tools and procedures, but also to gain experience with the system response. In this presentation, ADNOC will demonstrate how they use ETAP Operator Training (eOTS) with ETAP Digital Twin as their training environment for the existing power management system to ensure well-trained operators for their electrical networks, turbines, and generators, and to ensure they are capable of responding to any operating scenarios they face on a day-to-day basis, during a plant startup or shutdown, or any kind of disturbance in the electrical network.
Engineers face unique challenges when calculating DC Arc Flash incident energy for Battery Energy Storage Systems (BESS). Battery short circuit current is highly variant, and factors such as battery chemistry, and how the installation arrangement of BESS have significant differences in short circuit behavior. As well, traditional methods of calculating DCAF have been determined to fall short when it comes to BESS. In this demonstration, these variations will be discussed, including PPE considerations. Following this, a demonstration of the Transient DC Arc Flash solution provided by ETAP solutions will be presented. The presentation will show the usefulness of model validation, and the importance of high quality analysis methods to provide better accuracy in DC AF analysis for BESS.
Stellenbosch Municipality is a local municipality in the Western Cape province of South Africa serving more than 200,000 customers. They were in search of a capable OEM partner to provide them with end-to-end support in establishing a SCADA Master Station in their Control Centre to supervise and operate their distribution network. Further, they needed assistance to prepare the configuration of the SCADA Master Station system and allow for a completely integrated substation protection and control solution. With the help of Altek Solutions (System Integrator of ETAP in South Africa), this project was executed to meet the customer’s objective. This demonstration discusses the new SCADA Master Station at the Municipal Control Centre, which was implemented in various phases. The first phase was establishing SCADA at the Control Centre and connecting 7 substations. The next phase will be to add-on DMS & OMS capabilities to the SCADA system. ETAP was selected for this phase due to its modular and scalable platform to build on top of the ETAP SCADA system to meet their need of a Distribution Management System easily in future.
In most cases, SCCAF (Short Circuit Coordination Arc Flash) studies are done by engineering firms, which then submit reports to facility owners. The challenge is that those reports tend to be lengthy (up to 5,000 pages), not engaging, and hard to grasp for facility personnel. ETAP's powerful graphical and presentation tools can help make those reports livelier, informative, and more engaging. This case study will discuss how you can summarize lengthy power studies reports within just a 30-minute interactive meeting, and highlight how the final ETAP model can be used, with its powerful graphical interface and presentation tools, including Data Blocks, Multiple Presentation layers, Sequence of Operations, and Arc flash calculator.
This presentation discusses the Electrical Information Management System (EIMS) in use at Kuwait Oil Company, a power reservation model-based integration solution designed for oil and gas production. The aim was to achieve flexible and configurable approval workflows, integrated with user access management and various notification methods, to optimize operation, enhance visualization, and improve asset management within their complex electrical networks. Their EIMS integrates smart meters with ETAP and GIS, enabling efficient communication, real-time updates, and enhanced reliability of the electrical system. The pilot project includes real-time power monitoring, reduced site visits, expedited workflow, and centralized management of work order processes. The presentation also covers the challenges faced in power reservation planning and the specific ETAP solutions implemented, including NetPM and ETAP eWeb.
Nuclear plants in the United States are governed by federal regulations requiring that the electrical power system provide sufficient capacity and capability to the nuclear plant. As part of this analysis, traditional approaches to manually perform single motor start calculations can be tedious and time-consuming. Also, the manual evaluation of the data can easily introduce errors. This presentation takes a closer look at degraded voltage relays (DVRS) and an approach to simulation used by the TVA that is holistic, using ETAP to easily combine the study cases, the revisions, and the configurations into repeatable studies. The demonstration includes the use of an efficient solution using Python code with ETAP to run the studies and evaluate the resultant data.
This case study focuses on a green hydrogen project that applied a digital twin solution. The project is a 1.4 gigawatt wind farm in China, involving green hydrogen and ammonia manufacturing, with an estimated investment of $1-2 billion. The customer recognized the need for a software solution to optimize their processes and was looking for comprehensive coverage from power management to process management. The project's objectives included sizing optimization to reduce CapEx costs, process verification and optimization, and digital tools for control system specifications and electrolyzer selection. The digital continuity and unified digital solution offered by Schneider Electric encompassed feasibility study, detailed design, and future operation and maintenance stages. The project's complexity required linking power and process data, utilizing ETAP and AVEVA software solutions for modeling and simulation, and employing digital twin technology for process control. The proposed approach included utilizing ETAP for energy transition engineering, emphasizing the value of ETAP software applications, and leveraging software services to ensure the success of the implementation. The study also highlighted the value of digital continuity and building trust with the client to ensure the success of the project.
Drakenstein is a municipality in the western Cape province of West Africa supporting the electrical needs of 5 towns and close to 300,000 people. With limited visibility for our existing electrical network, the decision was made to upgrade the legacy equipment. With this, our vision is to embark on a digital journey to improve network efficiencies, reduce downtime, time of outages, and inadvertent tripping. In this case study, the phased approach to this transformation will be discussed, and the use of ETAP applications, analysis modules and the implementation of a digital twin to design and model the new electrical network. The presentation covers the use of ETAP load flow, short circuit, protection and relay coordination studies and subsequent hardware design planning and visualization using ETAP PSMS.
Skyworks has been manufacturing integrated circuit modules since 1969, investing in technology, facilities, and state-of-the-art equipment, yielding a world-class operation based on advanced processes and a highly trained workforce. As one of the largest employers in the Mexicali region with 3100 employees, Skyworks was in need of an accurate way of controlling the energy costs of all their plant processes. Skyworks has already been using ETAP Digital Twin for their electrical system at the medium voltage level for the last 5 years, and this contributed to electricity and gas efficiency at plants that resulted in 29,173 tons of CO2 reduction over the years. In the semiconductor manufacturing business, it's very important to monitor the electrical system throughout the plant, including medium and low voltage operations. In this demonstration, you’ll learn how Skyworks expanded their ETAP model to include low voltage equipment, including predictive simulation in order to improve the reliability of their entire electrical system, and power system modeling (PSMS) to manage and ensure the electrical system power quality and increase the energy efficiency of their entire electrical operation.
This presentation explores the critical role of ETAP's Network Project Manager (NETPM) in creating collaborative models for power systems. It addresses the industry-wide challenge of maintaining accurate, up-to-date electrical system data, highlighting the risks associated with outdated or inaccessible information. Carter Sanders introduces NETPM as a solution, demonstrating how it facilitates the creation of "living models" that evolve with the system. Key topics include the implementation of NETPM, focusing on user roles, permissions, and effective workflows. A customer success story illustrates the tangible benefits of NETPM, including reduced man-hours, faster information transfer, and improved risk mitigation. The presentation also covers important considerations for model management, data access, and adapting service models to incorporate NETPM effectively. By emphasizing the shift from static diagrams to dynamic, collaborative models, this talk aims to showcase how NETPM can enhance safety, reliability, and efficiency in power system management. It concludes by encouraging audiences to explore NETPM's potential in their operations, positioning it as a crucial tool for navigating the complexities of modern electrical systems.
The transition towards sustainable energy sources is driving innovative solutions in the offshore oil and gas industry. The presentation delves into the integration of a Wind Turbine Generator (WTG) into an existing Floating Production Storage and Offloading (FPSO) vessel to reduce carbon emissions. The technical and operational challenges of this integration are discussed, including load balancing, intermittency of wind energy, transformer energization, motor starting, protection coordination, and maintaining operational reliability. The study utilizes simulations with tools like HOMERPRO, ETAP, and PSCAD to assess the technical feasibility of integrating the WTG and Battery Energy Storage System (BESS) into the FPSO power system. Various studies, including load flow, short circuit, motor acceleration, transient stability, voltage ride through, harmonic analysis, protection coordination, and transformer energization are conducted to ensure the effectiveness and efficiency of the proposed system. There is great potential for reducing the operational carbon footprint of FPSOs by incorporating renewable energy sources and using software simulations to address the complexities and considerations involved in such integration.
Weidmueller is a pioneer of industrial connectivity, with customers around the world involved in building electrical control cabinets. In this case study, you’ll gain a better understanding of the complexities and bottlenecks in a traditional manufacturing workflow, and how Weidmueller has applied new strategies that work with software solutions such as SEE Electrical to improve efficiency at various phases. The demonstration includes the data engineering connection with ETAP SEE Electrical, SEE Electrical Expert, and SEE 3D Panel+, and how these tools are used by customers to greatly improve wire processing and panel building.
Recognizing an opportunity to improve quality and manufacturing efficiency, Schneider Electric Power System North America sought an integrated approach to electrical design and wiring processes. They found the solution in ETAP SEE Electrical and began their transformation journey. In this demonstration, you’ll learn how Schneider Electric evaluated new methods against existing workflows. As a result, SEE Electrical Expert and SEE 3D Panel+ are now being implemented in manufacturing facilities to deliver more robust engineering designs, while SEE One Panel has been adopted to automate manufacturing with wiring machines.
